Arduino MKR ZERO
- Rapid code development using examples
- Connects to EmStat Pico Development Board
- Connects to EmStat4M Development Board
PalmSens usually responds to your quotation request within one business day.
Description
The EmStat Pico is designed to be integrated into any microcontroller based system using just 4 wires (5V, Gnd, TX, RX). Figure 1 shows example setups firstly using an Arduino MKR as a master controller and secondly using a USB to UART convertor to interface to a PC. In both setups the EmStat Pico is connected with a Screen Printed Electrode (SPE) for common electrochemical measurements such as Cyclic Voltammetry (CV). More information about the Arduino MKR ZERO: https://store.arduino.cc/arduino-mkrzero
Figure 1: EmStat Pico system integration
A) Control via an Arduino MKR ZERO module
B) Controlled directly from a PC via a USB to UART convertor
Downloads
| Name | Type | Last updated | |
|---|---|---|---|
| MethodSCRIPT code examples MethodSCRIPT code examples include: <br>- MethodSCRIPTExample_C <br>- MethodSCRIPTExample_C_Linux <br>- MethodSCRIPTExample_C# <br>- MethodSCRIPTExample_Arduino <br>- MethodSCRIPTExample_Python <br>- MethodSCRIPTExample_iOS <br>- MethodSCRIPTExample_Android <br>Every code example comes with a "Getting Started" document. | Software | 07-07-22 | |
| Arduino MKR Zero with EmStat Pico dev board This document describes how to connect an Arduino MKR Zero to the EmStat Pico development board | Application Note | 20-04-20 |
